Heavy Duty Disc Harrow

Product Description

1BZN series extra-heavy-duty off-set disc harrows are mainly used for cleaning away stubble of plants before tillage, or uncultivated land and in sticky heavy clay soil fields. They could be used as a plow for primary tillage in dry cultivated fields. Their discs have been divided into two gangs notched discs, the dislocation of the design for front and rear disc gang, and disc gang on both sides of V to disc overall non-symmetrical, work angle can be adjusted. The surface of the field after harrowing is level and the crushing and clearing ability of the harrow is satisfactory.
1BZN series harrows have three varieties disc spacing for choices,different disc spacing has different effect: -230mm and 240mm suitable for multi-purpose;-270mm suitable for deep coarse plow stubble plowing,or without the plow surface farming. The series disc harrows can be freely choosed different sizes discs according to actual needs. And can changed the weight of the Disc Harrow by filling method. All fitted with hydraulic tubelyss rubber wheel for transport. They are easy to be transported and change direction on the edge of fields.

Model
unit
1BZN-2.3
1BZN-2.5
1BZN-3.0
1BZN-3.5
1BZN-4.0
1BZN-4.5
size
cm
520*250*136
520*280*136
520*330*136
540*380*136
550*430*136
582*480*136
Weight
kg
1660
1760
1930
2100
2380
2580
Width
m
2.3
2.5
3.0
3.5
4.0
4.5
Depth
cm
24
Spacer
mm
270
Discs
pc
18
20
24
28
32
36
blade
mm
660×6
 Type of bearing

 The double-sealed grease immersed bearings, double taper roller
Bearing
set
20
22
24
28
32
36
 Axle of disc
mm
 Round 42
tyre
set
2
Tyre model
-
11L-15,12PR
Productive
ha/h
1.3
1.5
1.7
1.9
2.2
2.5
Power
kw
53-66
53-73.5
58.8-88
73.5-100
88-110
100-120
linkage

                                                        Trailed
