Heavy Duty- Disc Harrow

Product Description

BZ series heavy-duty off-set disc harrows are mainly used for cleaning away stubble of plants before tillage, or uncultivated land and in sticky heavy clay soil fields. They could also be used as a plow for primary tillage in dry cultivated fields. Their discs have been divided into front and rear two gangs notched discs, the dislocation of the design for front and rear disc gang, and disc gang on both sides of V to disc overall non-symmetrical, work Angle can be adjusted. The surface of the field after harrowing is level and the crushing and clearing ability of the harrow is satisfactory.
The series disc harrows are using rigid steel mail body, fitted with hydraulic rubber wheel for transportation and spring leveling equipment. They are strong and durable and easy to be hook up, simple to be adjusted, and easy to be transported and change direction on the edge of fields, especially suitable for large farm.

 Model1BZ-2.01BZ-2.21BZ-2.51BZ-3.01BZ-3.41BZ-4.01BZ-4.4
 5020x2250x11605120x2400x11805120x2920x11805120x3490x11805120x3960x11805680x4300x11805580x4680x1180
Overall Dimension (LxWxH) (mm)
 Weight (kg)1180126013801500175019502400
 Working width (m)22.22.533.444.4
 Quantity of disc18202428323640
Spacing of disc (mm)230
 Dia. of disc (mm)660 (650)
Max. working depth (mm)200
Ground clearance (mm)>160
LinkageTrailed
Productivity (ha/h)1.11.31.41.71.92.42.8
Matched power  (kw)47.7~5955~66.258.8~7466.2~8873.5~10095~120100~132

Heavy Duty- Disc Harrow
Heavy Duty- Disc Harrow
Heavy Duty- Disc Harrow
Heavy Duty- Disc Harrow


Contact us if you need more details on Disc Harrow. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Disk Harrow、Heavy Duty Disc Harrow. If these products fail to match your need, please contact us and we would like to provide relevant information.
