Fold Wing Heavy Duty Disc Harrow

Product Description

1BZDZ series wing-folded heavy-duty Disc Harrow are mainly used for cleaning away stuble of plants before tillage,or crushing clods after tillage on uncultivated land and in sticky heavy clay soil fields,they can also be used as a Plough for primary tillage in dry culdtivated fields. The series produced are all fitted with hydraulic rubber wheel for transportation.It is easy to be transported and change direction on the edge of fields.
Specifications:

ModelUnit1BZDZ-4.41BZDZ-4.81BZDZ-5.3
Overall dimension cm580x450x150580x495x150580x540x150
Weightkg3100-31503250-33003400-3450
Working widthm4.44.85.3
Working depthcm20
Blade spacingmm230
No of discpc404448
Dia.of discmm660
Transport clearancemm>260
Productivityha/h4.44.85.3
Matched powerkw105-110115-120125-130
Linkage Trailed
 Fold Wing Heavy Duty Disc Harrow

Fold Wing Heavy Duty Disc Harrow
Fold Wing Heavy Duty Disc Harrow
Fold Wing Heavy Duty Disc Harrow
Fold Wing Heavy Duty Disc Harrow
Fold Wing Heavy Duty Disc Harrow
Fold Wing Heavy Duty Disc Harrow


Contact us if you need more details on Disc Harrow. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Disk Harrow、Heavy-Duty Disc Harrow. If these products fail to match your need, please contact us and we would like to provide relevant information.
